FL-2420W (24V/200W) - IP67 WATERPROOF LED DRIVER (NON-DIMMABLE)


    UL Approved Product

    PART NUMBER: FL-2420W

    INPUT FEATURES:

    RATED INPUT VOLTAGE: 100Vac to 240Vac
    RATED INPUT FREQUENCY: 50Hz/60Hz
    INPUT CURRENT: 2.8A max. & 100Vac.
    INRUSH CURRENT: 30A max. at 100-240Vac input for a cold start at 77F.
    EFFICIENCY: higher than 89% at 100-240Vac input and output full load (4.2A).

    OUTPUT FEATURES:

    RATED OUTPUT WATTAGE: 200 WATTS
    RATED OUTPUT VOLTAGE: 24.0VDC
    RATED OUTPUT CURRENT: 0.0A-8.4A
    SHORT-CIRCUIT OUTPUT POWER: HICCUP MODE (HICCUP(3W))
    LINE REGULATION: ≤1%
    LOAD REGULATION: ≤5%

    PROTECTIONS:

    OVER - CURRENT PROTECTION: The power supply shall be hiccupped and no damage shall occur when output current reaches to its over-current protection trigger point (set@ Max load 120-300% ). The power supply shall be self - recovery when the fault condition is removed.
    SHORT - CIRCUIT PROTECTION: The power supply shall be hiccupped(input power less than 3W) and no damage shall occur when any output operating in a short circuit condition under any line condition for an indefinite period of time. The power supply shall be self - recovery when the fault condition is removed.
    OVER - VOLTAGE PROTECTION: The power supply shall be hiccupped and no damage shall occur when output current reaches to its over- voltage protection trigger point (set@ Max output voltage 120-180%). The power supply shall be self - voltage when the fault condition is removed.
    ENVIRONMENTAL OPERATING CONDITIONS: The power supply shall be capable of operating continuously in any mode without performance deterioration in the following environmental conditions.
    Ambient Temperature: 32F ~ 104F
    Relative Humidity: 10% ~ 90%
    NON-OPERATING: The power supply shall be capable of withstanding the following environmental conditions extended periods of time, without sustaining electrical or mechanical damage and subsequent operational deficiencies.
    Ambient Temperature: -22F ~ 158F
    Relative Humidity: 10% ~ 90%
